Fault

Commons Issues with Allen-Bradley PowerFlex Drives

For detailed PowerFlex 70 information: For Allen-Bradley Drives Technical Support:. In this manual we refer to the PowerFlex 70 Adjustable Frequency AC Drive as; drive, PowerFlex 70 or PowerFlex 70 Drive. To help differentiate parameter names and LCD display text from other text, the following conventions will be used. PowerFlex® 753 AC Drives are cost-effective and easy to use in general purpose applications requiring safety features. They come standard with built-in I/O, which is ideal for machine builders and system integrators who want to reduce engineering costs, deliver machines to market faster, and meet end user demand for more productive machines. The VFD is giving Ground Fault. What might be the possible reasons? The VFD is Allen Bradley PowerFlex 400 1) Any Phase inside the terminal of motor is touching with the motor frame or body. 2) An phase inside the connection terminal strip of VFD is touching with metallic frame or metallic. The codes will appear in these parameters in the order they occur (b007 Fault 1 Code = the most recent fault). Repetitive faults will only be recorded once. Page 107 Programming and Parameters 3-55 Advance Display Group (continued) d313 Fault 2 Time-min Related Parameter(s): A195, d317 Displays the value of the d317 Elapsed Time-min. On the PowerFlex 755T if the converter current limit is set to zero a Fault 13068 SW Bus Over Volt See Tech note: 1071031-PowerFlex755T - Drive Sets Current Limit to Zero If your inverter is being powered by an active front end, the PE-B jumper must be removed, regardless of the grounding on the power system.

Powerflex 753 Fault Code List

Troubleshooting a faulted drive can be a tough endeavour. We’re here to help! The list below features some of the most common reasons why Allen-Bradley PowerFlex drives can fault and how to solve those issues. If you’ve tried all of the tips below and there’s still an problem with your drive, it might be time to contact your service provider for a repair or replacement. Contact us today for support!

Problems and Solutions for Allen-Bradley PowerFlex Drives

Powerflex Fault CodesPowerflex fault code 13
Contamination/Corrosion
Disconnect power and remove contamination (metal shavings, dust) with compressed dry air. The Allen-Bradley Powerflex drive should be sent in for service if it’s soaked with oil or other liquid contaminants.
Loose connections
Electronics are limited to their wiring. Vibrations, physical manipulation or relocation may loosen terminal connections. Verify and secure all terminal connections.
Missing power phase
Check input voltage and verify power is on all phases.
Bad cables
Over time and after constant use, cables will wear out from physical damage and contamination. If you have haven’t swapped out your cables in a while, secure a new cable and try again.
Seized cooling fans
Overheating is the biggest enemy to electronic circuitry. Proper ventialtion requires that fans have been cleaned and devoid of any debris.
Wrong parameters
This issue can occur when system memory leaks due to voltage transients and the values change. Backup the parameters using the HIM and reset the drive to factory default, then restore the correct parameters.
Binded load
This will usually cause an overcurrent fault. Check gear, fans, pulleys or worm gears for proper operation.

Allen-Bradley PowerFlex Drives

Powerflex Fault Codes 59

755 powerflex fault codesFault

Powerflex Fault Code 13

Alarm Numbers and Descriptions

Powerflex Fault Code 6037

  • 2 Auxiliary Input
  • 3 Power Loss
  • 4 Under Voltage
  • 5 Over Voltage
  • 7 Motor Overload
  • 8 Heatsink Over Temp
  • 9 Transister Over Temp
  • 12 HW Over Current
  • 15 Load Loss
  • 16 Motor Thermistor
  • 17 Input Phase Loss
  • 24 Decel Inhibit
  • 25 Over Speed Limit
  • 29 Analog In Loss
  • 33 Auto Restart Tries
  • 36 SW Over Current
  • 38 Phase U to Ground
  • 39 Phase V to Ground
  • 40 Phase W to Ground
  • 41 Phase UV Short
  • 42 Phase UW Short
  • 43 Phase VU Short
  • 48 Params Defaulted
  • 49 Drive Powerup
  • 51 Fault Queue Cleared
  • 52 Faults Cleared
  • 63 Shear Pin
  • 64 Drive Overload
  • 71-75 Port 1-5 Adapter
  • 77 IR Volts Range
  • 78 Flux Amps Reference Range
  • 79 Excessive Load
  • 80 AutoTune Aborted
  • 81-85 Port 1-5 DPI Loss
  • 87 IXo Voltage Range
  • 91 Encoder Loss
  • 100 Parameter Checksum
  • 101 User Set 1 Checksum
  • 102 User Set 2 Checksum
  • 103 User Set 3 Checksum
  • 104 Power Board Checksum 1
  • 105 Power Board Checksum 2
  • 106 Incompatible MCB-PB
  • 107 Replaced MCB-PB
  • 108 Analog Calibration Checksum
  • 111 Enable Hardware
